Resistor Color Code Calculator
Quickly determine resistor values using the standard color coding system. Perfect for students, engineers, and electronics enthusiasts.
Interactive Calculator
Select the colors for each band to calculate resistance
Understanding Resistor Color Codes
What are Resistor Color Codes?
Resistor color codes are a system of colored bands painted on resistors to indicate their electrical resistance and tolerance. This standardized system allows engineers and technicians to quickly identify resistor values without needing to measure them with instruments.
Developed in the 1920s, this coding system is still widely used today for through-hole resistors. The color bands represent numbers according to a standardized color chart, with each color corresponding to a specific digit, multiplier, or tolerance value.
How to Read Resistor Color Bands
Most resistors have 4 or 5 color bands:
- 4-band resistors: The first two bands represent significant digits, the third band is the multiplier, and the fourth band indicates tolerance.
- 5-band resistors: The first three bands represent significant digits, the fourth band is the multiplier, and the fifth band indicates tolerance.
- 6-band resistors: Similar to 5-band but with an additional band for temperature coefficient.
To read a resistor, start with the band closest to the end. The tolerance band is usually spaced farther apart or is gold/silver.
Color Code Chart
Practical Examples
Yellow, Violet, Red, Gold
Yellow = 4, Violet = 7, Red = ร100, Gold = ยฑ5%
Result: 47 ร 100 = 4,700ฮฉ or 4.7kฮฉ ยฑ5%
Brown, Black, Black, Red, Brown
Brown = 1, Black = 0, Black = 0, Red = ร100, Brown = ยฑ1%
Result: 100 ร 100 = 10,000ฮฉ or 10kฮฉ ยฑ1%
Why Use Color Codes?
Resistor color coding offers several advantages:
- Universal Standard: Recognized worldwide by electronics professionals
- Quick Identification: Values can be determined at a glance
- Space Efficient: Small resistors can display information without text
- Durability: Colors don’t rub off like printed text
While surface-mount resistors use numerical codes, through-hole resistors continue to use the color band system due to its effectiveness and tradition.
What is a resistor color code?
It’s a color-based marking system to indicate resistor values.
How does the Resistor Color Code Calculator work?
It interprets the colored bands on resistors and converts them into resistance values.
What do the resistor color bands represent?
Each color represents a number for significant digits, multiplier, and tolerance.
What is the difference between 4, 5, and 6 band resistors?
More bands offer higher precision and additional tolerance/temp coefficient info.
Can this calculator work for surface-mount resistors?
No, SMD resistors use a numeric code, not color bands.
Is this calculator accurate for all resistor types?
Itโs accurate for standard color-coded resistors.
How do I read a 4-band resistor?
The first two bands are digits, third is multiplier, fourth is tolerance.
How do I use this tool for 5-band resistors?
Input the five color bands and the tool will show resistance and tolerance.
Can I calculate resistance in ohms using color codes?
Yes, the tool provides values in ohms, kilo-ohms, and mega-ohms.
What tolerance values can resistors have?
Common tolerance bands include gold (ยฑ5%), silver (ยฑ10%), and others.
Are temperature coefficients included?
Yes, for 6-band resistors, the 6th band shows temperature coefficient (ppm/K).
How do I know which side to start reading from?
Usually, the tolerance band (gold/silver) is on the right side.
Can I use this calculator on mobile devices?
Yes, itโs mobile-friendly and responsive.
Is this tool free to use?
Yes, it’s completely free.
What units does the calculator use?
Ohms (ฮฉ), kilo-ohms (kฮฉ), and mega-ohms (Mฮฉ).
What color is used for the digit 0?
Black represents 0.
What color represents the multiplier of 1000?
Orange, which corresponds to 10ยณ.
What does a gold band mean in tolerance?
It means ยฑ5% tolerance.
Can beginners use this calculator easily?
Yes, itโs designed for students, hobbyists, and professionals.
Is there a resistor color code chart available?
Yes, the calculator includes a color code chart for reference.
